ARDUINO UNO + L298N MOTOR DRIVER which has the same microcontroller on official Arduino UNO where you can select Arduino/Genuino UNO in Arduino IDE to develop the program. With onboard 5V 3A buck converter power supply and a wide range of motor operating Voltage, the driver performs very dynamically in small brushed motor applications as well as 1.2A continuous current motors per channel which can be raised up to Total 4A.
Features
Power Status LED.
16MHz crystal.
5 mm standard DC plug-in jack for Input supply
On-Board Arduino UNO with USB Port
On-Board DC motor Driver L298N.
On-board 5V 3A SMPS circuit.
On-Board power supply on-off switch
Port extensions for all ports with detailed pin labeling for easy identification of pins
Specification
| Min-Max Input Voltage Range | 9-15V |
| Recommended Input Voltage | 12V |
| Mounting Hole Dimensions | 3mm |
| Length (mm) | 93 |
| Width (mm) | 75 |
| Height (mm) | 21 |
| Weight (gm) | 50 |
