The use of lithium, nickel or Pb batteries is not a problem for the B6 Nex. The cut-off voltage can even be set manually and professionals benefit particularly from the intermediate storage. Because the device remembers the last set value. The “Scan to Go” feature can also be used in conjunction with the associated “SkyCharger” app. Batteries are provided with QR codes on which the core data is stored. One scan is enough and the B6 Nex automatically begins the (dis-) charging process.
Features
With the dual power AC/DC input, B6 Nex can charge the 1-6 cell Li-ion or LiPo batteries at a maximum charge current of 10A.
The built-in Bluetooth 5.0 enables B6 Nex’s connectivity with smartphones.
The app can push notifications reminding users that the charge or discharge is completed or there is a firmware upgrade.
With B6 Nex, charging becomes a faster and more convenient experience!
Specification
SKYRC B6 Nex 1-6S LiPo Charger with Bluetooth With dual AC/DC power input, this charger is suitable for charging and discharging of LiFe/ Lilon/ LiPo/ LiHV/ NiMH/ NiCd/ PB batteries.
Protection is built-in such as high/low input voltage, and input/output reverse, reverse polarity protection.
Specification
| Display | Type: VA LCD |
| Buttons and Port | External Port: 2-6S Balance Socket-XH, Battery Socket, DC Input, AC Input Buttons: Increase Button, Decrease Button, Start/Stop Button |
| Power | DC Input:10-30V Charge: 200W Discharge: 10W AC Input:100-240V(50-60HZ) Charge:50W Discharge:10W |
| Battery | BatteryTypes/Cells: LiPo/LiIon/LiFe/LiHV: 1-6cells NiMH/NiCd: 1-15cells Pb: 1-10S(2-20V) Battery Capacity Range: NiMH/NiCd: 100-50000mAh LiPo/LiIon/LiFe/LiHV: 100-50000mAh Pb:100-50000mAh |
| Charge Voltage |
NiMH/NiCd: Delta peak detection LiPo: 4.18-4.25V/cell LiFe: 3.58-3.7V/cell Pb: 2.4V/cell LiIon: 4.08-4.2V/cell LiHV: 4.25-4.35V/cell AGM/COLD: 2.45V/cell |
| Discharge Cut-off Voltage |
NiMH/NiCd:0.1-1.1V/cell LiPo: 3.0-3.3V/cell LiFe: 2.6-2.9V/cell Pb: 1.8V/cell LiIon: 2.9-3.2V/cell LiHV: 3.1-3.4V/cell Charge Current:0.1A-10.0A Discharge Current:0.1A-2.0A Balance Cells:1-6 cells Balance Current:1000mA/cell Max Safety Timer:1-720minutes off Charge Method: CC/CV for lithium types and lead(Pb) batteries Delta-peak Sensitivity for NiMH/NiCd. |
| Size and Weight | Case Material: Plastic Case Size:112x75x38mm Weight:237.7g |
| Working and Storage | Operating temperature:0℃-40℃ Working humidity:0%-75% Storage temperature:-10℃-70℃ Storage humidity:0%-75% |
