Features
Onboard 1A (maximum) 5V voltage regulator.
Onboard 500mA (maximum) 3.3V voltage regulator.
0-5V digital outputs with 3.3V compatible inputs.
14 Digital I/O Pins (6 PWM outputs).(4 pin used for Motor driver)
6 Analog Inputs (Can be digital I/O too).
Maximum current up to 10A continuous.
ISP 6-pin Header.
32k Flash Memory.
16MHz Clock Speed.
R3 Shield Compatible.
Specification
| Driver Model | Cytron Dual 10A UNO Robot Controller |
| Operating Voltage (VDC) | 3.3 |
| Peak Current (A) | 30 |
| Continuous Current (A) | 10 |
| No. of Channels | 2 |
| Over-Current Protection (A) | Yes |
| Thermal Protection | Yes |
| LED Indicator | Yes |
| Cooling Fan | No |
| Arduino Sheild | No- can be used with Wire connection |
| Polarity Protection | No |
| Dimensions in mm (LxWxH) | 100 x 76 x 13 |
| Weight (gm) | 52 |
