The FS-05 is a liquid flow sensor. This flow switch is available in 22mm compression fitting, rugged brass housing material with low volts, and ac control circuitry switching at less than 1 L/min. Typical applications include mains water control, power shower, central heating systems, circulation pump protection, and cooling systems.
Specification
| Operating Voltage | 230V AC |
| Operating Current | 3A |
| Inlet/Outlet Diameter | 22 mm |
| Metal part | Brass |
| Plastic Part | Noryl |
| Cable length | 1 meter |
Features
Operates from a small head of water
Vertical mounting
Suitable for hot and cold potable water
Reed Switch Reliability (UL File E153493)
Meets UL 94-HB flammability rating
Easy installation
Operating temperature range from -30°C to 100°C
Maximum pressure of 10bar at 20
IP65 rated
