Features:
Compact size, easy to install and use.
All jumpers hit the ON position to indicate 16 subdivisions (4988) or 32 subdivisions (8825).
Jm connection motor; Jv Connects 5V and 12V-24V Power Supply.
E /S /D /G of Jc corresponds to Enable /Step /Dir /Gnd driving signal output on the connection respectively.
Specification
| Suggested Match | 3A004 |
| Color | Red |
| Material | Metal+PCB Board |
| Length (mm) | 41 |
| Width (mm) | 34 |
| Height (mm) | 11 |
| Weight (gm) | 10 |
