TowerPro Servo Motors are optimum-quality and affordable cost servos.! They are suitable for a wide range of applications, including RC aircraft, automobiles, and robotics, Or just to have some fun with whatever crazy project you’re working on
Wire Description:
Specification
| Model | SG90 |
| Weight(gm) | 9 |
| Operating Voltage (VDC) | 3.0 ~ 7.2 |
| Operating Speed @4.8V | 0.12sec/60° |
| Operating Speed @6.6V | 0.1sec/60° |
| Stall Torque @ 4.8V (Kg-Cm) | 1.2 |
| Operating Temperature (°C) | -30 to 60 |
| Dead Band Width ( μs) | 5 |
| Gear Type | Glass Fiber |
| Rotational Degree | 360º |
| Servo Plug | JR |
| Cable Length (cm) | 25 |
| Length (mm) | 23 |
| Width (mm) | 12.6 |
| Height (mm) | 30 |
